This economic paper rewinder machine is applied to slit jumbo paper roll into small rolls. The economic paper rewinder machine adopt ordinary brake and it has the features of easy using and good performance.
This economic paper rewinder machine is applied to slit jumbo paper roll into small rolls. The economic paper rewinder machine adopt ordinary brake and it has the features of easy using and good performance.
Model | SANSE-1600 |
Max. width of jumbo roll | 1600mm |
Min. width of jumbo roll | 600mm (min 400mm only for special order) |
Max. diameter of jumbo roll | 1300mm |
Working speed | 0-140m/min |
Quantity of blades | 16 |
Power supply | 10.5KW, 380V, 50HZ |
Weight | 3500KG |
Paper stand | Hydraulic paper stand without spindle. |
Hydraulic paper stand, easy for loading paper roll.
Automatic centering system, small tolerance.
Suspended tension system. Keep the tension steady.
Heavy body with steady performance.
Separate the rolls with Min.1-2mm distance to avoid adhesion.
Single bottom roller rewinding system. Easy for unloading.
Unwinder: Unrolls the large master roll of paper.
Slitter: Cuts the wide paper web into narrower strips.
Rewinder: Rewinds the slit strips onto smaller cores.
Tension Control System: Maintains consistent tension in the paper web throughout the process.
Splicers: Automatically join the end of one roll to the beginning of the next, ensuring continuous operation.
A paper rewinding machine converts large rolls of paper into smaller, more manageable ones. It works by unwinding a large master roll, slitting it into narrower widths using rotating blades, and then rewinding the slit strips onto smaller cores. This process involves precise control of tension, speed, and alignment to ensure consistent roll quality and minimize waste.
Production Volume: Consider the required output capacity.
Paper Type and Thickness: Select a machine that can handle the specific materials you will be processing.
Roll Width and Diameter: Choose a machine with appropriate size capabilities.
Budget: Determine the available budget and compare prices from different manufacturers.
Maintenance Requirements: Consider the ease of maintenance and the availability of spare parts.
